Sometimes, the common wire is hidden in the wall behind the thermostat. Number of heat pump compressor stages Select 1 Stage default or 2 Stages. Looking inside my 2010 Rheem gas furnace As you can see in the photo above, this furnace does not have a C-wire hooked up.

However, they can be different depending on who wired the unit and their color coding system. Step 9 Label the R, Y, G and W wires for assistance. I followed Insx on the web and met the g fan wire on the furnace to the c terminal. Rh stands for Red-Heat and Rc stands for Red-Cool. My house had old wire No C wire Which is the common wire…or known as ground. Modern furnaces use a control board that usually is met on a time increment for both the starting and stopping of the fan when in heat mode while older furnaces used a mechanical type of relay call the fan limit control that control the fan based on the temperature in the heat exchanger.

That thermostat battery powered and programmable works fine. Special Offer: Carson Dunlop Associates offers InspectAPedia readers in the U. Check your local home improvement stores, or local tool rental, for rental availability. Well, I installed a 120v to 24v transformer which has a R and a C terminal an ran an additional thermostat wire from the transformer to Rc and C on the thermostat.

Thermostat Wiring Color Code Chart - Take the two screws and drive them into the wall, making sure that the plate remains level as you do so.

Warning: This is a project for a confident DIYer. Also note that it may be against the law, code, or regulations to do this without a permit, or it might void your insurance or warranty. Check your local regulations before continuing. What Is the Nest Thermostat and Why Would I Want One? The Nest Thermostat is one of the most popular smart thermostats on the market, mostly thanks to its unique design and easy-to-use user interface. So if you tend to turn down the heat when you go to bed and turn it back up when you wake up, the Nest will learn this and do it for you, without you having to program it manually. Will the Nest Thermostat Work in My House? If you see a handful of tiny wires in all sorts of different colors, then you likely have a low-voltage system, but if you see only 2-4 larger wires that are connected with wire nuts, then you likely have a high-voltage system. You can also look on the thermostat itself to see how many volts it is. Above: A typical high-voltage thermostat with 2-4 black and red wires. Above: A typical low-voltage thermostat, with multiple small wires in different colors. Step One: Remove Your Current Thermostat Locate your thermostat and turn it off. It will still be powered on, but you should turn off the heating, cooling, and fan. You might also have to turn off a third breaker for the wire that gives the thermostat power. Next, remove the thermostat body from the wall. If there is, you need to go back to the breaker box and try turning off another breaker. This next step is important. Take a photo of the current wire setup and note where each wire is running. You can also use the included wire labels in the Nest instructional booklet to mark the wires, but taking a photo and noting where the wires go is good enough. Next, unscrew the wires from their screw terminals using the screwdriver that came with your Nest. If there are any jumper cables i. Step Two: Install the Nest Thermostat Take the Nest base plate and put it on the wall where you want the Nest Thermostat to go. Use the built-in leveler to make it level. From there, use a pencil and mark where the two screws need to go—one on the top and one on the bottom. Otherwise, the included screws are self-tapping and can easily be driven into drywall without pre-drilling. Take the two screws and drive them into the wall, making sure that the plate remains level as you do so. To insert and secure a wire, press down on the button and insert the wire as far as it will go. Then lift up on the button. Next, take the main Nest Thermostat unit, making sure the Nest logo is at the top, and then simply push it in until it clicks into place. Remove the plastic that covers up the motion sensor. Go back to your breaker box and turn the power back on to every breaker that you turned off. Your Nest Thermostat will automatically boot up and the setup process will begin. Step Three: Set Up the Nest Thermostat The first step in setting up the Nest Thermostat is selecting your language. To navigate through setup as well as the different menus when you have it set up , spin the silver dial on the unit in either direction to move the selector on the screen, and then push on the entire unit to select it. The next step is connecting the thermostat to your WiFi network, so push on the unit to get started. Select your WiFi network from the list provided. Push on the unit to continue. This will display the local weather on your thermostat. Push on the unit to continue. Select the continent that you live in. Enter in your zip code by using the silver dial to select a number. Push on the unit to move to the next digit. Select where your thermostat is located in your house or apartment. Push on the unit to continue. If all looks good, push to continue. The next screen will confirm your system. After that, select the type of heating you have. The most common type is forced air heating, which will be the first option. Otherwise, use the silver dial to select temperatures for each one. Choose whether you want to test the heating, cooling, or just the fan. If you want, find your furnace or air conditioner and make sure that it powers up. First off, download the Nest app from the or , depending on your device. Enter in your email address and come up with a password for your Nest account. You can choose not to set it up right now you can do so later on. You can also share your Nest Thermostat with other people in the house so they can monitor and change the temperature from their own phone. You can also set this up later. To get an entry key, go to your Nest Thermostat and push on the unit to bring up the home screen. Scroll to the settings gear icon and select it. Enter in the seven-digit entry key shown on the screen. Once complete, your thermostat will say that it has successfully connected to your Nest account, and thus is connected to the Nest app on your phone. Your Nest Thermostat will now show up on the main screen of the Nest app. You can tap on it to bring it up and begin controlling your thermostat remotely. At this point, you can adjust the temperature of your Nest Thermostat right from your phone and from anywhere in the world. There are also a handful of settings that you should check out, so take the time to explore the app and check out to get acquainted.
